Item shown may not be actual product.Product and price information are subject to change without notice.
$64,087.20 *
*log in for dealer pricing
An added steel surcharge will be applied at time of order.
IMPULSE SERIES 40 18FT Frame Rack 4 Towers
Item Number: CAS450438
Supplier:
CHIEF AUTOMOTIVE TECHNOLOGIES
Note: The image shown is not the correct representation of the CAS450438
Description
Power and performance in one affordable package. The Chief impulse - E/VHT gives you the high-end features and capabilities you've come to expect from Chief at a price you can afford. Low Pressure System offers more Power and Tighter Control for faster, Higher Quality Repairs
Compare the quality and feature of the impulse-E/VHT with any other competitive system - and decide for yourself if it offers the quality, durability and features you need to increase your profitability and stay ahead of the competition.
Features
- Simultaneous multiple pulling
- 6 Variable working heights
- True 360-degree capability
- Four 10- Ton Towers
- Handheld control pendant
- Sure-Lock tower mechanism
Benefits
- Electric-over-hydraulic for smoother, quieter operations while generating 10 tons of pulling power and 10,000 lbs. of lift capacity
- Patented Sure-Lock mechanism pins and secures towers with one easy movement for added speed, accuracy, and safety
- All height and pull functions controlled from single hand-held pendant. No more hassles with foot pumps or charging lines!
Warranty
Limited one (1) year.
Product Specifications
- Pulling Force Per Tower: 10 Tons
- Deck Length: 18'
- Deck Width: 6' 8"
- Working Height: 19" to 40" - 4 stops
- Maximum Length: 22' 4"
- Maximum Width: 11' 2"
- Maximum Height: 10'
- Lift Capacity: 10,000 lbs
- Tie Down Openings: 172
- Power - U.S.: 120 VAC, 60 Hz, 20 Amp, Single Phase, Dedicated Line
- Power - International: 230 VAC / 50 / 60 Hz
